Technical Index:
Laser power: 150/200/300/400W (Optional)
Laser Type: CO2 Sealed-off laser glass tube, water-cooled
Engraving size: 1300*25000mm
Laser head: Movable with auto focus
Transmission: Rack
Driving: Servo motors
Engraving speed: 0-400mm/sec.
Cutting speed: 0-200mm/sec.
Laser Energy Control: Adjustable
Max. Scanning Accuracy: 25-2500DPI
Figure Supported: DST, HPGL (PLT), BMP, DXF, AI, DST, JPEG
Software Supported: TAJIMA, CORELDRAW, PHOTOSHOP, AUTOCAD, CAM
Color Separation: Yes, 256 layers
Machine Dimension: 3650*2100*1100mm
Packing size: 3750*2200*1300mm
Gross weight: 800kgs
Total Power: <1200W
Communication Connection: USB (off-line) or computer control
Working Voltage: 220V+/-10% 50Hz, or 110V 60 Hz
Moving System: DSP Professional Controlling System
Repeating Location: <+0.01
Special Feature:
-Movable laser head with auto focus lifting up down automatically
-Welded chassis with thick metal pipes
-Rack transmission
-Servo motors
-Upper-level gantry smoke extraction
Video:
https://youtu.be/gRi1y3NAtJM (Moveable laser head)
Qingdao Mektex Electronic Technology Co., Ltd, as a professional manufacturer and exporter of CNC laser engraving cutting marking welding cleaning machine, is dedicated to provide the best laser machines and services to global customers on high standard on high precise materials processing industry. SEE MORE
