Working size （X、Y、Z）

1300mm*2500mm*400mm

Lathe bed

Heavy-duty T-shaped bed, steel beam large gantry, feeding height 400 mm. Stainless steel sink

Working voltage

220V/3 phases or 1 phase by extra voltage stabilizer

Spindle power

HQD5.5KW water-cooled spindle*1

Inverter

FULING frequency converter

Main electric parts

Omron, CHNT, SIEMENS

Motor

Stepper motor (450B)

Driver

Stepper driver (860H)

Control system

NCStudio controller

Working table

Aluminum working table

Spindle speed

6000——18000rmp/min

Transmission system

X/Y adopt rack from German HERION，Z axis adopt ball screw of TBR2505 from Taiwan

Guide rail

X/Y/Z adopt Taiwan HIWIN guide rail

Oiling system

Manual

Engraving speed

6m/min---30m/min

Repeated positioning accuracy

±0.05mm
