Technical Index:

 Laser power: 150/200/300/400W

Laser Type: CO2 Sealed-off laser glass tube, water-cooled

Engraving size: 1500*3000mm

Chassis: Welded chassis/frame with thick metal pipes

Transmission: Servo motors

Driving: Servo motors

Engraving speed: 0-400mm/sec.

Cutting speed: 0-200mm/sec.

Laser Energy Control: Adjustable

Max. Scanning Accuracy: 25-2500DPI

Figure Supported: DST, HPGL (PLT), BMP, DXF, AI, DST, JPEG

Software Supported: TAJIMA, CORELDRAW, PHOTOSHOP, AUTOCAD, CAM

Color Separation: Yes, 256 layers

Machine Dimension: 3340*2150*1320mm

Packing size: 3440*2250*1420mm

Gross weight: 700kgs

Total Power: <1200W

Communication Connection: USB (off-line) or computer control

Working Voltage: 220V+/-10% 50Hz, or 110V 60 Hz

Driving Way: Servo motor

Transmission: Rack

Repeating Location: <+0.01

Video:

https://youtu.be/mSmDP_X7dV0    (400W Cut 15mm MDF)

https://youtu.be/eItHIPSX8do         (400W cut 20mm acrylic)

https://youtu.be/i-MUTaFPe_4        (400W cut 20mm MDF)

https://youtu.be/DYSurEtT-48         (300W cut engrave acrylic)

https://youtu.be/Micq0oB85qE       (300W cut 13mm plywood)
