Technical Index:
1 Laser power: 30W Fiber Laser
2 Working area: 100*100mm
3 Laser Wave length: 1064nm
4 Response time: 0.5ms
5 Frequency of pulse: 20-100KHz
6 Max marking depth: ≤0.4mm
7 Marking speed: ≤10000mm/s
8 Marking lines: 1-10 lines(in the marking area)
9 Minimum line width: 0.005mm
10 Minimum character: 0.15mm
11 Repeatability accuracy: ±0.001mm
12 Resolution ratio: 0.1mm
13 Marking content Text,pattern,date,bar code,etc
14 Operation system Microsoft Windows XP,Windows 2000, Window 7
15 Control software: MaCAD
16 Graphic format supported :bmp, jpg, gif, tga, Ai, bmp, dst, dxf, plt, png, tif etc.
17 Total power: ≤300KW
18 Operation temperature: 5℃-40℃
19 Relative moisture: ≤ 90%,no fog
20 Supply Voltage: 220V/50Hz; 110V/60Hz/10A
21 Life 50000 hours
22 Cooling: Air cooling
23 Packing size/G.W.: 57*25*49cm/14kgs
Video:
Qingdao Mektex Electronic Technology Co., Ltd, as a professional manufacturer and exporter of CNC laser engraving cutting marking welding cleaning machine, is dedicated to provide the best laser machines and services to global customers on high standard on high precise materials processing industry. SEE MORE
