Technical Index:
Laser power: 150/180/200/260/300/400W
Laser Type: CO2 Sealed-off laser glass tube, water-cooled
Engraving size: 2500*1300mm
Working Voltage: 220V+/-10% 50Hz or 110V 60 Hz
Cutting speed: 0-400mm/sec.
Repeating Location: ≤0.05mm
Laser Energy Control: Adjustable
Max. Scanning Accuracy: 25-2500DPI
Figure Supported: DST, HPGL (PLT), BMP, DXF, AI, DST, JPEG
Software Supported: TAJIMA、CORELDRAW、PHOTOSHOP、AUTOCAD、CAM
Color Separation: Yes, 256 layers
Lift Platform: Optional
Machine Dimension: 3340*2150*1320mm
Packing size: 3440*2250*1420mm
Gross weight: 700kgs
Total Power: <1500W
Operating temperature: 0-45℃
Operating Moisture: 5-95%
Communication Connection: USB (off-line) or computer control
Special Feature:
-Welded chassis with thick metal pipes
-Rack transmission
-Servo motors driving
-Upper-level gantry smoke extraction
-Hybrid laser head for metal nonmetal cutting
Video:
Stainless Steel Cutting:
Acrylic Cutting:
https://youtu.be/zw1ROPj4vnY (31mm acrylic)
https://youtu.be/m6TxpxzqfSM (13mm acrylic)
Plywood Cutting:
https://youtu.be/6N3jSOt28j8 (20mm wood)
https://youtu.be/IN8qRUYSeH0 (19mm Plywood)
Qingdao Mektex Electronic Technology Co., Ltd, as a professional manufacturer and exporter of CNC laser engraving cutting marking welding cleaning machine, is dedicated to provide the best laser machines and services to global customers on high standard on high precise materials processing industry. SEE MORE
