Technical Index:

Laser source : 2000W-10000W Fiber Laser

Working size: 1500mm*3000mm

Cutting thickness: 0.1-10mm (Depending on the material)

Position accuracy: 0.03mm

Repeat Precision: 0.02mm

X Axis Route: 3050mm

Y Axis Route: 1525mm

Z Axis Route: 120mm

Maximum cutting speed: 20m/min.

Operating temperature: 0℃-40℃

Workbench maximum load: 750kg

Drive type of X, Y axis: Imported servo drive

Servo motor: Imported servo motor

Laser Head: Bochu BLT

Control system: Bochu

Software support formats: AI, BMP, PLT, DXF, DST etc

Rack transmission: YCC

Guide Rail: Taiwan HIVIN Guide

Reducer: Motoreducer

Input Power: 380V 50Hz

Auxiliary gas: N2 ,O2

Machine size(L*W*H): 4780*2880*2400mm (Front), 3640*1870*740mm (Rear)

Net weight: 3000 kgs

Application:

Cutting on plate or tube in metal, mainly for cutting on SS, carton steel, manganese steel, galvanized plate, alloy plate, rare metal.

Widely used in kitchen appliance, electric control box, high-resolute device, mechanical equipment, electrical equipment, lighting,

poster, auto parts, display equipment, hardware and metal processing.

Video:

https://youtu.be/uqiGu7ucYIc           (1mm stainless steel by air)

https://youtu.be/YISlTaCEcwc              (3mm carbon steel by oxygen)

https://youtu.be/A6BRebAu0Bs           (2mm carbon steel by air)

https://youtu.be/eC_urvxhdeE             (1.5mm carbon steel by air)

https://youtu.be/znk8t8U29gs             (1mm galvanized sheet by air)

https://youtu.be/_j7hANVlMkk            (Steel Square Pipe/Tube with Rotary)

https://youtu.be/EHR4pCrkBdM   (Steel Round Pipe/Tube with Rotary)
