Technical Index:
1 Laser power: 20W/30W/50W Fiber Laser (Optional)
2 Working area: 100*100mm/150*150mm
3 Laser Wave length: 1064nm
4 Response time: 0.5ms
5 Frequency of pulse: 20-100KHz
6 Max marking depth: ≤0.4mm
7 Marking speed: ≤10000mm/s
8 Marking lines: 1-10 lines(in the marking area)
9 Minimum line width: 0.005mm
10 Minimum character: 0.15mm
11 Repeatability accuracy: ±0.001mm
12 Resolution ratio: 0.1mm
13 Marking content Text,pattern,date,bar code,etc
14 Operation system Microsoft Windows
15 Graphic format supported :bmp, jpg, gif, tga, Ai, bmp, dst, dxf, plt, png, tif etc.
16 Total power: ≤300KW
17 Operation temperature: 5℃-40℃
18 Relative moisture: ≤ 90%,no fog
19 Supply Voltage: 220V/50Hz
20 Life 50000 hours
21 Controller: Linux
22 Cooling: Air cooling
23 Machine size/G.W.: 31*28*15.5cm, head 29*23cm/6.6kgs
Video:
Qingdao Mektex Electronic Technology Co., Ltd, as a professional manufacturer and exporter of CNC laser engraving cutting marking welding cleaning machine, is dedicated to provide the best laser machines and services to global customers on high standard on high precise materials processing industry. SEE MORE
